Felling Wedge Titan 50

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product ID11933799

  ManufacturerEDER

  CharacteristicsFor large timber and heavy-duty wedging
  Lifting force: 15 tonnes

  For use in heavy timber felling as an alternative to heavy-duty wedging

  Advantages compared with conventional wedges:
  - The wedge can be screwed back and repositioned if the lifting height is insufficient
  - Effort-saving and ergonomically beneficial operation thanks to high lifting forces and favourable gear ratios
  - Increased safety when felling on slopes
  - The risk of falling deadwood is reduced thanks to vibration-free wedging
  - Enclosed drive spindle prevents dirt ingress and resulting damage to the drive mechanism

  Technical specifications:
  - Dimensions L x W x H (mm): 240 x 118 x 72
  - Scope of delivery: with ratchet
  - Max. lifting height (mm): 50
  - Lifting force (t): 15
  - Max. torque (Nm): 750
  - Lift / crank revolution (mm): 2
  - Additional information: Wedge feed: 100 mm
