Bc60/6 Electric Control Valve for Forestry Crane

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product IDFM980861

  Manufacturer

  CharacteristicsFlow: 70 l/min

  Technical specification:
  - Valve block for forest loader, domestically designed in Finland
  - Specially designed to work with the ERGO control system
  - Suitable for use in tractors or for replacing old steering in forestry machines with modern electronic control
  - BC 60/6 control valve with 6 proportional valve sections
  - For open hydraulic system (circulating)
  - The valve is intended for 12 V systems; if used in a 24 V system, the coils must be replaced with 24 V-compatible ones
  - Connections: 1/2"
  - Flow: 70 l/min
  - Max. working pressure: 300 bar
  - Max. tank line pressure: 15 bar
  - Max. pilot pressure: 30 bar
