Solenoid Directional Valve 3/8" - max. 50 l/min

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product IDAMV502E

  Manufacturer

  CharacteristicsWith emergency operation
  2x double acting

  Electrically controlled directional control valve with adjustable safety valve. The valve comes with a lever.
  The valve package is suitable for, among others, sweepers, agricultural machinery, hydraulic presses, cranes, concrete pumps, and front loaders.

  Technical specifications:
  - load-holding valve
  - material: housing made of cast iron, sections made of chrome-plated carbon steel, sealing made of NBR
  - 2 sections
  - function 2x double-acting
  - max. flow 50 l/min
  - max. operating pressure 350 bar
  - max. return line pressure 30 bar
  - P-port G 1/2"
  - A/B-port G 3/8"
  - T-port G 1/2"
