  Product IDPV300148

  Manufacturer

  Characteristics6200 l/min
  3" hose outlet

  - Power transmission via PTO shaft 540 rpm
  - Max. vacuum 95 % 28 Hg / continuous vacuum 80 % 23,6 Hg
  - Power consumption max. vacuum 9 kW
  - Power consumption with maximum pressure (3 bar) 18 kW
  - Recommended tank volume 2-9 m³
  - Air cooling
  - Pressure lubrication
  - 3" hose outlet in aluminium, continuously adjustable to the desired position
  - Check valve and 4-way valve integrated into the pump
  - Shaft secured with bolts in the rotor
  - 6 vanes, 60° angle, vane dimensions 280 x 69 x 7,5 mm (note the chamfer!)
  - Gear oil pump and lubrication unit as standard equipment

  Supplied without oil; check the oil level in the pump and gearbox before use:
  - Pump ISO VG 100-type mineral oil 1,7 l (-149 3,76) e.g. 30W monograde oil MB127616
  - Gearbox ISO VG 460-type oil, e.g. 80W-90 gear oil MB142122 or 80W-140
  - Can also be factory-ordered as 1000 rpm, hydraulic motor and direct-drive versions and special vanes
