Petrol Generator KS 15-1E 1/3 ATSR

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product IDKS15-1E1_3ATSR

  ManufacturerKönner & Söhnen

  CharacteristicsEffekt (kW): 11.5/15.6

  HIGH-PERFORMANCE ENGINE
  Powerful and reliable 1-cylinder air-cooled engine (18.5 hp), high-performance and cost-effective, meeting European quality standards (including emissions and noise). Each engine features a K&S company stamp and an individual serial number for production and service quality control.

  VTS SYSTEM
  The unique and innovative VTS (Voltage Transfer Switch) phase changeover system delivers equal power in single-phase (230 V) and three-phase (400 V) operation, with virtually no power loss. Each mode has its own power switch.

  ERGONOMIC CONTROL PANEL
  The user-friendly ergonomic control panel enables easy operation of the entire unit without special skills and is equipped with sockets for full power output and a modern LED display (hour meter, frequency, voltage, oil alarm). The panel also includes an emergency stop switch.

  ATS OUTPUT
  The ATS unit (Automatic Transfer Switch) automatically starts the generator and transfers the load when the main power supply is disconnected, and automatically stops the generator when the mains power is restored.

  GENERATOR WITH 100% COPPER WINDING
  Könner & Söhnen generators are equipped with a high-quality synchronous generator with 100% copper winding, capable of withstanding maximum loads and ensuring long-term reliable operation.

  STEEL FUEL TANK
  Könner & Söhnen generators are equipped with an enlarged steel fuel tank (55 l), extending operating time without refuelling. The fuel level indicator is integrated into the tank.

  Technical specification:
  Voltage, V: 230/400
  Max./Rated Power (230 V), kW: 11.5/11.0
  Power Factor, cosφ: 1 (230 V)/0.8 (400 V)
  Max./Rated Power (400 V), kVA: 15.6/15.0
  Frequency, Hz: 50
  Current (max.) 230/400 V, A: 48/22
  Sockets: 1 x CEE 230 V 63 A, 1 x CEE 400 V 32 A
  Fuel Tank Capacity, l: 55
  LED Display: Voltage, frequency, operating hours, oil alarm
  Noise Level Lpa (7 m)/Lwa, dB: 72/97
  DC Output Power, V/A: +
  Engine Model: KS 780
  Engine Type: Petrol-powered TWIN-CYLINDER, four-stroke air-cooled
  Engine Power, hp/kW: 22.0/16.18
  Fuel Type: Petrol
  Engine Oil Capacity, l: 1.5
  Engine Displacement, cm³: 750
  Output Control: Intelligent Automatic Voltage Regulation (AVR) system
  Engine Start: Electric
  Battery (A·h): 36
  Generator Winding: Copper
  Protection Class: IP23M
  Net Dimensions (LxWxH), mm: 797 x 705 x 805
  Gross Dimensions (LxWxH), mm: 807 x 715 x 905
  Net Weight, kg: 155
  Gross Weight, kg: 170.0
