Orbital motor MSY315 Sh 14T shaft

Qty:

Add to cart

Lägg i kundvagnen

• Info
• Stock status

  Product IDHMSY315SH

  Manufacturer

  CharacteristicsAxeldiameter 31,75 mm
  Displacement 314,9 cm³

  - Reinforced and kraftig motor that tål 15-20% more torque än a vanlig motor
  - Applications såsom sop- And borstmachines
  - Replaceablet with e.g. Danfoss 151F2213
  - SAE A-4-montering with 4 bultar
  - Connectionar G 1/2"
  - Connection, dränering G 1/4"
  - Frånluftsdon (disc valve)
  - SH-shaft 1 1/4" 14-spårig ANSI B92.1-1970
  - Displacement 314,9 cm³/r
  - Rotation 240 / intermittent 285 rpm
  - Max. torque 90 / intermittent 96 daNm
  - Max. power 17 / intermittent 20,2 kW
  - Max. pressure continuous 210 / intermittent 250 / peak 300 bar
  - Max. flow continuous 75 / intermittent 90 l/min
  - Weight 12,4 kg
